Summary
ZLSN2000 is the first generation module, but with 30mA low power consumption and ten years application experience, it still has good utility value in industrial fields. The module provides 19 dual pin, plugging in user PCB to use, can connect with RJ45 of network transformer or connect RJ45 after network transformer.2. Characteristic of ZLSN2000.
Features
- Can configure its network parameters, serial parameters, login password, and others through the embedded Web server.
- The Web server supports password logins to prevent arbitrary modification.
- Support for cross gateways: the ability to connect a serial device server to any host on the Internet with a public network IP.
- Supports 1200bps~460800bps (customizable 1M or 1.5m baud rate).
- Support for 9-bit data sending function: the 9th bit can be used to distinguish between data frame and address frame in 485 communication with no, odd check, even check, 1, 0.
- ZLVirCom configuration tool can automatically find ZLAN networking devices on the network.ZLVirCom.
- Support virtual serial port.
- Support data write protection, prevent arbitrary tampering.
- Supports default configuration start.
- LINK pin connection instruction.
- Hardware flow control CTS/RTS.
- 1KV network surge protection.
Communicate Interface
- Ethernet
- 10/100 Mbps
- Protection
- Built-in 2KV surge protection
Serial Interface
- Serial
- TTL Level Serial Port
- Serial Qty.
- 1
- Parity Bit
- None, Even, Odd, Space, Mark
- Data Bit
- 5～9
- Stop Bit
- 1,2
- Flow Control
- RTS/CTS,DTR/DCR,XON/XOFF
- Baud Rate
- 1200bps～460800bps(customizable 1M or 1.5m baud rate)
Software
- Protocol
- TCP,HTTP,UDP,ICMP,ARP,IP,DNS,DHCP
- Virtual Serial Port Platform
- Windows 98/2000/XP/WIN7/WIN8
- Setting method
- ZLVirCom, WEB browser, serial port like-AT command
Electrical Character
- Voltage Input
- DC5V, less than 45mA
Mechanical Character
- Size
- L×W=4.3cm×2.6cm
Environment
- Running temp., humidity
- -40～85℃，5～95% RH
- Storage temp., humidity
- -40～85℃，5～95% RH
