Industrial wireless router series products are a kind of Internet of Things communication equipment for remote data acquisition and remote monitoring, widely used in power system, industrial monitoring, traffic management, weather monitoring, water dispatching, environmental monitoring, coal and oil and other industrial fields, is one of the essential key equipment in the development of industrial Internet of things. To provide users with convenient, fast and efficient device networking solutions. Moving Star industrial wireless router adopts high-end core chip design scheme, stable communication, reliable performance, powerful function, superior industrial protection ability, especially suitable for harsh industrial environment.
1. Support LTE/3G/Ethernet/Wi-Fi network access
2. Support full Netcom 7 modes and 13 bands
3. Support APN+VPN virtual private network
4. Support SNMP protocol and private Mib definition
5. Industrial-grade design, stable and reliable
| Wireless parameters | |
| Product model | VS775W |
| Network standard | China Mobile/China Unicom/China Telecom 4G, 3G and 2G |
| Operating frequency band | LTE FDD：B1/B3/B5/B8 LTE TDD：B38/B39/B40/B41 WCDMA：B1/B8 TD-SCDMA：B34/B39 CDMA：BC0 GSM：900/1800MHz |
| Transmission rate | FDD-LTE: Max 150Mbps (downlink) / Max 50Mbps (uplink) TDD-LTE: Max 130Mbps (downlink) / Max 35Mbps (uplink) WCDMA: Max 42Mbps (downlink) / Max 5.76Mbps (uplink) TD-SCDMA: Max 4.2Mbps (downlink) / Max 2.2Mbps (uplink) CDMA2000: Max 3.1Mbps (downlink) / Max 1.8Mbps (uplink) CDMA: Max 384Kbps (downlink) / Max 128Kbps (uplink) |
| 2/3/4G network specifications | |
| Number of antennas | 1 root |
| Interface form | SMA Connector (Outer Screw Inner Hole) |
| SIM card | Quantity: 1 pc; Voltage: 3V, 1.8V; Size: Standard large card (small card can be used by purchasing card sleeves) |
| Serial port specifications | |
| Serial data port | 5Pin terminal, RS-232/RS-485 (both modes cannot be used at the same time) |
| Serial baud rate | 300~230400bps |
| Ethernet port specifications | |
| Network port type | RJ45, support cross-direct connection automatic switching, 1.5kV electromagnetic isolation protection |
| LAN interface | 4 x 10/100Mbps adaptive Ethernet ports |
| WAN interface | 1 x 10/100Mbps adaptive Ethernet port |
| WI-IF specifications | |
| Antenna standards | 2 SMA ports (outer spiral and inner hole), support 802.11b/g/n |
| Software Features | |
| Web configuration | |
| DNS domain name | |
| Wi-Fi signals support WPA/WPA2, WEP and other encryption methods | |
| Carrier's private network APN is supported | |
| Port mapping feature | |
| Traffic rate limiting and QoS are supported | |
| DHCP, Static Routing, PPPoE, Static IP Functions | |
| Network diagnostics: Ping, Traceroute, and Tcpdump (network packet capture tools) are supported | |
| Local system logs, remote logs, and scheduled local logs can be saved | |
| Support web upgrades, etc | |
| It supports wired and wireless multi-network simultaneous online, link backup, dual-mode backup, wired and wireless backup, and other functions | |
| Watchdog function, automatic detection of network disconnection, automatic restart of dialing failure, and one-key factory default reset | |
| Immediate restart and scheduled restart functions are supported | |
| Support serial port to network transparent transmission: TCP Server/TCP Client/UDP Server/UDP Client and other transmission protocols are supported | |
| Support peanut shell inner network penetration function | |
| Dynamic DNS domain name resolution is supported | |
| VPN Client (PPTP/L2TP/OPENVPN/GRE/SSTP/IPSEC) and VPN Server (PPTP/L2TP/IPSEC) | |
| SNMP protocols and private Mib definitions are supported | |
| Hardware parameters | |
| power supply | 9V～36V（DC） |
| Operating current | 180mA@12V |
| Power connector | DC power supply base, terminal power supply |
| Power protection | Surge-proof, ESD-protected, anti-reverse polarity |
| Operating temperature | -20℃～70℃ |
| Store humidity | -40~85°C/5%~95% RH (no condensation) |
| Exterior dimensions | 185.0×112.0×33.0mm(L*W*H)(excluding mounting ears) |
| Installation: | Wall-mounted, guide rail (additional rail accessories required) |
