SZMW-HDR-30-24
Input
Voltage Range 85~264VAC(277VAC available) 120~370VDC(390VDC available)
Cold Start 30A/115VAC 60A230VAC
Frequency Range: 47~63Hz
Efficiency(TyP): 90
AC Current(TyP): 1.2AJ115VAC 0.8A230VAC
Inrush Current(TyP) : Cold Start 30A/115VAC 60A230VAC
Protection
Overload: 105%~160% of rated output power, automatic recovery after removal of abnormal load conditions
Overvoltage: 30~36V, protection mode: output shutdown, clamped by Zener diode
Environment
Operating Temperature: -10~~+60°C
Operating humidity: 20~90%RH, non-condensing
Storage temperature and humidity: -20~+85℃.10-95% RH
Temperature coefficient:+0.03%7℃(0~60℃)
High quality capacitors
Adopting high quality electrolytic capacitors with high capacity, low loss, durable and safer.
Pure copper transformer
Full-turn coil winding, reliable performance, full power and stable operation.
EML filter
High efficiency, good performance
Strong anti-interference ability, work
Voltage Range 85~264VAC(277VAC available) 120~370VDC(390VDC available)
Cold Start 30A/115VAC 60A230VAC
Frequency Range: 47~63Hz
Efficiency(TyP): 90
AC Current(TyP): 1.2AJ115VAC 0.8A230VAC
Inrush Current(TyP) : Cold Start 30A/115VAC 60A230VAC
Protection
Overload: 105%~160% of rated output power, automatic recovery after removal of abnormal load conditions
Overvoltage: 30~36V, protection mode: output shutdown, clamped by Zener diode
Environment
Operating Temperature: -10~~+60°C
Operating humidity: 20~90%RH, non-condensing
Storage temperature and humidity: -20~+85℃.10-95% RH
Temperature coefficient:+0.03%7℃(0~60℃)
High quality capacitors
Adopting high quality electrolytic capacitors with high capacity, low loss, durable and safer.
Pure copper transformer
Full-turn coil winding, reliable performance, full power and stable operation.
EML filter
High efficiency, good performance
Strong anti-interference ability, work
